Clamp On Ultrasonic Flow Meter Wall Mounted

We offer Clamp On Ultrasonic Flow Meter Wall Mounted which has two transducers that serve as ultrasonic transmitters and receivers. The transducers are either put into the open pipes outside the surface or clamped to it. The transit time flow meter counts the number of seconds it takes for an ultrasonic signal to go across a pipe and be picked up by a second transducer. The flow is then calculated by comparing the ultrasonic signals upstream and downstream times. The transit time would be the same in both directions if there was no flow through the pipe.

Salient Features:

• Cost-effective and versatile
• High accuracy 1.0% reading
• Non-invasive, no moving parts, no pressure drop, no maintenance
• Easy and economical installation, no pipe cutting
• Wide measurement range 0.2  12m/s
• Wide pipe size range (DN 15  6000mm)
• Suitable for all commonly used pipe materials
• Bi-directional measurement. Totaliser display for net, positive and negative flow
• Ideal for both clean and opaque liquid flow measurement

Applications:

• Chemical, petrochemical and process industries
• Fertilizers industries
• Pharmaceutical industries
• Food and drug industries
• Sugar, beverage industries
• Paper and pulp industries
• Water and waste water management
• Dredging industries
• Mining industries.
