Vortex Flow Meter
Product Details:
- Usage Industrial
- Color Multicolor
- Product Type Flow Meter
- Material Metal
- Power Supply 24 VDC / 230 V AC
- Accuracy +/--0.5% for Liquids , +/- 1% for Gas & Steam %
- Display Type LCD for Flow Rate & Totaliser
- Click to View more
X
Vortex Flow Meter Price And Quantity
- 10 Piece
Vortex Flow Meter Product Specifications
- 24 VDC / 230 V AC
- LCD for Flow Rate & Totaliser
- Flow Meter
- +/--0.5% for Liquids , +/- 1% for Gas & Steam %
- Metal
- Industrial
- Multicolor
Vortex Flow Meter Trade Information
- Cash in Advance (CID)
- 1000 Piece Per Month
- 1 - 7 Week
- Asia Middle East Central America South America Western Europe Eastern Europe North America Australia Africa
- All India
Product Description
Product Details
| Diameter | 10,15,20,25,32,40,50,65,80,100,150,250,300,(300 1000) |
| Temperature | Piezoelectric:-40 60C Capacitive:-40 300 C |
| Material | Stainless steel material |
| Vibration Acceleration | Piezoelectric:0.2g Capacitive:1.0 2.0g |
| Accuracy | 1.0%FS;1.5%FS; Insert type:2.5%FS |
| Flow ratio | 1:6 1:30 |
| Power supply | Flow Sensor:12VDC/24VDC / Battery: 3.6V |
| Output | Pulse ,4 20mA Output ; Battery supply can not provide any output |
| Explosion | ExdIIia CT2 T5 or ExdII CT2 CT5 |
| Protection | IP65 or IP68 |
Features:
- Lattice LCD display
- Easy operation
- Configure with temperature/pressure senor. For temperature sensors, Pt100 or Pt1000; For pressure sensor, gauge pressure sensor or absolute pressure sensor
- Multiple Outputs can be optional: Two-Wire 4-20mA, Three-Wire pulse and Three-Wire equivalent output
- Excellent nonlinearity correction function, greatly improve the appearance of linearity
- Spectral analysis, improve the ability of anti-interference and vibration resistance
- A variety of measuring medium: vapor, liquid, gas and natural gas, etc.
- Low power consumption, a dry cell can maintain at least 3 years
- Automatic switching ability of the working modes: Battery supply, Two-Wire and Three-Wire
- Self-checking function: the rich self-checking information make easy maintenance and debugging
- Independent password setup, the parameters setup, total flow reset and calibration can be set with different- level passwords, it is convenient for management
- Three-Wire system supports RS485 communication The display unit can be selected and user-defined
Technical Specifications
| Diameter Nominal (mm) | Liquid | GAS & STEAM | ||
| Measuring Range(m3/h) | Frequency Range(Hz) | Measuring Range(m3/h) | Frequency Range(Hz) | |
| 10 | 1.1 14 | |||
| 15 | 0.3 5 | 35 600 | 2.2 20 | 260 2000 |
| 20 | 0.6 10 | 29 420 | 4 36 | 210 1900 |
| 25 | 1.2 16 | 25 336 | 8.8 50 | 190 1140 |
| 32 | 1.8 20 | 18 264 | 10 150 | 156 1080 |
| 40 | 2 40 | 10 200 | 27 205 | 140 1040 |
| 50 | 3 60 | 8 160 | 35 380 | 94 1020 |
| 65 | 4 85 | 6 120 | 35 800 | 94 940 |
| 80 | 6.5 130 | 4.1 82 | 86 1100 | 55 690 |
| 100 | 15 220 | 4.7 69 | 133 1650 | 42 536 |
| 125 | 20 350 | 3.2 57 | 150 2000 | 38 475 |
| 150 | 30 450 | 2.8 43 | 347 4000 | 33 380 |
| 200 | 45 800 | 2 31 | 560 8000 | 22 315 |
| 250 | 65 1250 | 1.5 25 | 890 11000 | 18 221 |
| 300 | 95 2000 | 1.2 24 | 1360 18000 | 16 213 |
