Clamp On Ultrasonic Btu Meter
Product Details:
- Product Type Btu Meter
- Usage Measuring Tool
- Color Multicolor
- Material Plastic
- Power Supply Electricity
- Display Type Digital Only
- Click to View more
Clamp On Ultrasonic Btu Meter Price And Quantity
- 10 Piece
Clamp On Ultrasonic Btu Meter Product Specifications
- Multicolor
- Electricity
- Measuring Tool
- Plastic
- Btu Meter
- Digital Only
Clamp On Ultrasonic Btu Meter Trade Information
- Cash in Advance (CID)
- 1000 Piece Per Month
- 1 - 7 Week
- Western Europe Asia Australia Eastern Europe Central America Middle East South America North America Africa
- All India
Product Description
Product Details
| Mounting | wall mounting, panel, local |
| Transducer type | clamp-on, spool piece, or insertion |
| Display | LCD with backlight, 2 x 20 characters 1-line, non-backlit 7 digit LCD (ILD version) Displays energy rate, total consumption, temperature, instantaneous flow rate, accumulated flow rate, velocity, time |
| Keypad | 4 x 4 tactile-feedback membrane keypad |
| Pipe Size | 25-6000mm |
| Pipe Material | Carbon Steel, Stainless Steel, Ductile Iron Copper, PVC, Aluminum, Asbestos Fiberglass, etc. |
| Output Signals | 4-20mA , Impedance 0-1k, pulse, relays, Isolated OCT for alarms (on/off with buzzer) |
| Inputs | Two RTD channels, and additional inputs |
| Product Code | UFC250W |
| Port | Mumbai |
| Payment Terms | T/T |
| Delivery Time | 2-3 Days |
Key Features:
- Horizontal or vertical Installation
- Transducer Max Temp: -20C to +160C
- Accuracy: +/-1% of reading above 0.6ft/sec / 0.2 m/sec
- Outputs available: 1x 4-20mA , 1x Pulse Output , 1x Alarm Output (All configurable)
- ModBus output
- Ingress Protection: Display= IP65, Transducers= IP65 (IP68 on request)
These ultrasonic flow meters can be used on virtually any pipe size or material, are non-invasive and are therefore not prone to the levels of deterioration that are seen by traditional intrusive flow meters. Mbus converter, Radio Pulse transmission and GSM/GPRS Telemetry / logging options on request.
Features:
- High accuracy - 1% of reading
- Bi-directional flow measurement
- Wide range of fluid velocities - 0.03 105 feet/sec.
- Transducers for pipe sizes ranging from to 240" (15 to 6000 mm)
- Measures energy consumption rate and total
- No moving parts,
- Fixed and Portable version
- Proven ultrasonic technology for flow measurement and PT 100 for temperature
- Clamp-on, spool piece or insertion mounting for flow measurement
- RS485 and Modbus communication protocols available
- 4-20mA and pulse outputs with available relays and alarms
- Data logger function - includes time & date, totalizer, diagnostics
- Fast response time - less than 1 second
- NIST traceable calibration certificate (optional
Applications
- BTU metering system
- HVAC/Energy Monitoring
- Building Automation / HVAC
- Energy consumption supervision and water conservation management
- Cooling system and air conditioning/glycol solutions
- Heating & District Heating Solutions & Systems
- Smart Heat meteing
- Thermal energy measurement (heating and conditioning) and water metering (cold and worm)
